Crank handle switching device KAS-M
Crank handle switching device KAS-M is designed for installation at metro railway sections for storage and closure (blocking) of the removable handle (crank handle) of the electric switch mechanism.
Crank handle switching device KAS-M is designed for installation at metro railway sections for storage and closure (blocking) of the removable handle (crank handle) of
the electric switch mechanism.
It is installed near switch points that enables to improve operability if the point is to be switched manually.
Power supply of the crank handle apparatus is 24 VDC, signalization power supply of the crank handle apparatus is 24 VAC.
The crank handle apparatus is made in U climatic version, category 3 per GOST 15150-69 and of protection IP54 per GOST 14254 for operation in tunnels and on the ground, meets requirements for classifi cation groups MS3 and K8 (U version) by impact of mechanical loads and climatic factors correspondingly — per OST 32.146–2000.
the electric switch mechanism.
It is installed near switch points that enables to improve operability if the point is to be switched manually.
Power supply of the crank handle apparatus is 24 VDC, signalization power supply of the crank handle apparatus is 24 VAC.
The crank handle apparatus is made in U climatic version, category 3 per GOST 15150-69 and of protection IP54 per GOST 14254 for operation in tunnels and on the ground, meets requirements for classifi cation groups MS3 and K8 (U version) by impact of mechanical loads and climatic factors correspondingly — per OST 32.146–2000.
| Switchgear weight, kg, maximum: | 8,0 |
| Consumption current, A, maximum: | 1 |
| Depth: | 180 |
| Maximum cycle time, at DC (duty cycle)=100%, s, : | 300 |
| Rated power, at DC=100%, W, maximum: | 14 |
| Rated voltage of alternating current, 50 Hz, V : | 24±4 |
| Width: | 202 |
| Height: | 268 |
