POWER SUPPLY CABINET SET FOR AUTOMATICS AND TELEMECHANICS SHPAT
Power supply cabinet set for automatics and telemechanics for metro train running is a part of the uninterruptible power supply of automatics and telemechanics devices for train running.
Power supply cabinet set for automatics and telemechanics for metro train running Cabinet set SHPAT YUKLYA.565418.003 is a part of the uninterruptible power supply of automatics and telemechanics devices for train running. The SHPAT is installed in the relay building of automatics and telemechanics of train running of the signaling, centralization and blocking service of the metro railway.
Extreme air temperature during operation is from + 1°C to + 40°C; relative air humidity is up to 60% at + 20°C.
SHPAT YUKLYA.565418.003 CABINET SET INCLUDES THE FOLLOWING:
— automatic load transfer cabinet (overall dimensions: 840 х 2170 х 625, weight 250 kg);
— input and distribution cabinet (overall dimensions: 840 х 2170 х 625, weight 300 kg);
— supply conversion cabinet (overall dimensions: 1040 х 2170 х 625, weight 300 kg).
Service life of the SHAT set until decommissioning is minimum 12 years.
